Mediant 500L MSBR
All-in-one SOHO/SMB router combining access, data, voice and security in a single device.
Mediant 500L MSBR
Open High performance multi-core architecture tooltip

High performance multi-core architecture

Open Survivability and resilience tooltip

Survivability and resilience

Open Analog and digital voice interfaces tooltip

Analog and digital voice interfaces

  • All-in-one SOHO/SMB router
  • High performance, multi-core architecture
  • Access, data, voice and security in single platform
  • Multiple and redundant WAN options


The Mediant 500L multi-service business router (MSBR) is an all-in-one SOHO/SMB router combining access, data, voice and security in a single device. The Mediant 500L MSBR is perfectly suited for managed data, SIP trunking, hosted PBX and cloud-based services, and enables services providers to deploy flexible and cost-effective solutions.

The Mediant 500L is an ideal solution for SOHOs and SMBs supporting 4 WAN interfaces, up to 8 LAN (Gigabit Ethernet) interfaces with a PoE option, 120KPP, up to 60 SBC sessions and up to 8 voice channels.


  • Integrated business router with access, data, voice and security in a single, cost-efficient platform
  • Ideal for managed data, cloud, SIP trunking and hosted PBX services
  • Consistent high performance with multi-core architecture
  • Survivability and resilience of the data and telephony services in the event of WAN failure


  • All-in-one product, perfect for any all-IP migration scenario
  • Four redundant access types – xDSL, fiber, Ethernet and LTE
  • LAN interface with powerful routing, switching and firewall
  • Different analog and digital voice interfaces with integrated SBC


WAN Interfaces
  • 10/100/1000 Base-T copper Ethernet interface
  • Dual-Mode SFP (100Base-X and 1000Base-X)
  • Support for ADSL2+, SHDSL, VDSL2 vectoring
  • Embedded 4G/LTE cat 4 modem up to 150 Mbps down and 50Mbps up speed
Voice Channels Up to 8 voice channels (analog or BRI)
Enterprise SBC Sessions 60 sessions
LAN Interfaces 4 x 10/100/1000 Base-T ports
Physical Dimensions (W) 296 mm, (D) 160 mm, (H) 51 mm
